6-56 ELECTRICAL SYSTEM / WING TIP LIGHTS
ICON A5 / MAINTENANCE MANUAL CHANGE C2
GTV-IC1400-0-AJ (LIGHT, POSITION & STROBE, LE-RH)
GTV-IC1600-0-AJ (LIGHT, POSITION & STROBE, TE-RH)
GTV-IC1400-1-AJ (LIGHT, POSITION & STROBE, LE-LH)
GTV-IC1600-1-AJ (LIGHT, POSITION & STROBE, TE-LH)
8-32x5-8TXFL82-316SS-BUN (SCREW, FL BUNA-N, 8-32x5-8T)
Aircraft System and Number
03—Electrical System
Consumables
ICA012078 (LUBRICANT, GENERAL PURPOSE) Tef-Gel
®
1. Inspect the interior of the wing tip for water, debris, or anything else amiss and correct any
issues.
2. Inspect the surfaces where the light’s seal will contact the wing, ensuring that it is undamaged
and clean.
NOTE: If installing a trailing edge (TE) light, remove the adhesive backing
from the included seal (Figure 6-14) prior to installation.
3. Connect the light’s wire harness connectors.
a. For the LH Trailing Edge light, connect D9003P on light to D9003J on aircraft wire
harness.
b. For the RH Trailing Edge light, connect D9007P on light to D9007J on aircraft wire
harness.
c. For the LH Leading Edge light, connect D9002J1 and D9002P2 on light to D9002P1 and
D9002J2 on aircraft wire harness respectively.
d. For the RH Leading Edge light, connect D9006J1 and D9006P2 on light to D9006P1 and
D9006J2 on aircraft wire harness respectively.
4. Attach light to wing using SCREW, BUNA-N, 8-32x5-8Twith a light coat of Tef-Gel
®
. Verify light
is seated and torque screw to 13 in-lb
f
with a T15 Torx drive
NOTE: If not in place, install the trailing edge light fences. (See “Wing
Trailing Edge Light Fence Replacement” on page 17-16.)
VERIFICATION METHOD:
The task is complete when the light is secure.
RELATED INFORMATION:
"Condition and 100-Hour Inspection—Wings" on page 3-11
"Removal of Wing Tip Lights" on page 6-53
