9-88 FLIGHT CONTROLS / YAW CONTROLS
ICON A5 / MAINTENANCE MANUAL CHANGE C3
No
Special Tools Required
Aircraft Cable Tensiometer
Parts Required
As needed based upon inspections and condition of parts. Contact ICON Aircraft for assistance
as needed. A list of part numbers in the rudder cable system is below.
Number Name Quantity
ICA001941 WASHER, PLAIN, CRES,.250X.875X.120 1
ICA002125 SPACER, WATER RUDDER BELLCRANK 1
ICA002388 CONTROL CABLE, RUDDER 2
ICA002392 BELLCRANK WELDMENT,WATER RUDDER 1
ICA007023 BELLCRANK WELDMENT, RUDDER 1
ICA007292 BELLCRANK, INTERCONNECT, RUDDER PEDAL 2
ICA007938 BEARING BLOCK, TORQUE TUBE, RUDDER 1
ICA007939 PIN, BEARING, TORQUE TUBE, RUDDER 1
ICA009269 BUSHING, FLANGED, .250X.438X.102X.063 1
ICA009484 HOUSING, BEARING, YAW TORQUE TUBE 4
ICA009488 TORQUE TUBE WELDMENT, YAW, AFT 1
ICA009490 CONTROL CABLE, YAW, FUSLG, CNTR-LH SIDE 1
ICA009492 CONTROL CABLE, YAW, FUSLG, CNTR-RH SIDE 1
ICA009493 BEARING SUPPORT, YAW TORQUE TUBE, UPR 4
ICA009498 CENTERING SPRING ASSY, 11LB/IN 1
ICA009503 STOP, YAW SECTOR 2
ICA009519 TORQUE TUBE WELDMENT, YAW, FWD 1
ICA009521 BUSHING, PLAIN, NITRONIC, .191X.280X.500 1
ICA010413 ROD END, BBRG, EXT THD, .190-32X_.188, RADIAL GROOVE 2
ICA012055 PUSHROD, RUDDER 1
