FLIGHT CONTROLS / YAW CONTROLS 9-89
CHANGE C3 ICON A5 / MAINTENANCE MANUAL
CHAPTER 9
ICA012239 CLIP, LOCKING, TURNBUCKLE, LONG, .042 WIRE 2
1191-3CN380 INSERT, HELICAL COIL, CRES, 10-32X.380 2
92778A121 SET SCREW, HEX, SST, 10-32X.5 2
93013A330 SPACER, AL, .250X.500X.500, BLACK 1
9852 RADIAL SHAFT SEAL 1
AS3582-030 O-RING, VQM (SILICONE), 1.614X.070 1
CN609CR3P NUT PLATE, TWO LUG, ADH BND, .190-32 12
CN609CR4P NUT PLATE, TWO LUG, ADH BND, .250-28 1
MS20392-1R
23
PIN, STR, HEADED, DRILLED SHK, CRES, .125X.719 2
MS21151-7C ROD END, BBRG, MALE, 10-32, SLOTTED 2
MS21251-A3S TURNBUCKLE BODY, CLIP LKG, AL, .093X.190-32X2.25 2
MS21251-B5L TURNBUCKLE BODY, CLIP LKG, BRASS, .156X.250-28X4.00 2
MS21256-1 CLIP, LKG, TRNBKL, 1.078 4
MS21256-2 CLIP, LKG, TRNBKL, 1.955 10
MS24566-3B PULLEY, CONT, AFB, .188X1.51 2
MS24665-151 PIN, COTTER, CRES, .063X.500 2
MS27641-4 BEARING, BALL, AFR AFB, INTMD DUTY, .250X.750X.281 2
MS27641-8 BEARING, BALL, AFR AFB, INTMD DUTY, .500X1.125X.375 4
MS27646-41 BEARING, BALL, AFR AFB, EX LD, 1.06X1.50X.281 1
NAS428H3-7 BOLT, MACH-CRWND HEX HD, ADJUSTING, CRES, 10-32X.875 2
NAS75C4-00
6
BUSHING , PLAIN, CRES, .250X.375X.188 1
NAS77C3-01
5
BUSHING, FLNGD, UNLINED, CRES, .190X.150 2
VH-112-S16 RETAINING RING, PLAIN, LIGHT DUTY, 316SS, 1.25X.025 4
Number Name Quantity
