13-8 INSTRUMENTS (AND AVIONICS) / TROUBLESHOOTING
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 13
13.2.2 Transponder
Contact an FAA approved technician or repair facility to perform transponder tests and inspections per
14 CFR Part 43, Appendix F.
RELATED INFORMATION:
"Interval Maintenance—Calendar Intervals" on page 3-5
13.2.3 Magnetic Direction Indicator Calibration
The following directions should be used to calibrate the magnetic direction indicator of the A5.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
Owner/Pilot
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
10—Instruments (and Avionics)
Consumables
None
The magnetic direction indicator is part of the attitude indicator (AI), which is located in the center of
the flight instrument cluster.
If the magnetic direction indicator becomes erratic, when deviations in the heading are noticed, or due
to new electrical interference, the instrument can be re-calibrated.
TASK INSTRUCTIONS:
1. Proceed when in flight and at least 3 minutes from turning on the instrument.
2. Press and hold the two buttons at the same time until the message “Gathering Mag Data” is
shown on the display (approximately 10 seconds).
NOTE: The display will rotate through the 3 screen modes until the
message appears. The operation resets any previous compensa-
tion and the instrument begins to gather data for 10 minutes to
perform the magnetic compensation.
