13.3.6 Remove Instrument Cluster
Use the following to remove the instrument cluster to perform maintenance on instrument gauges or
annunciator panel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
10—Instruments (and Avionics)
Consumables
None
A pitot-static-AOA leak test is required whenever a pitot-static or AOA tube is disconnected. (See
“Pitot Static Leak Check Operation” on page 13-75.)
TASK INSTRUCTIONS:
1. Remove cluster hood shell by pulling upon the aft side and sliding hood towards aft aircraft.
2. Remove four #8-32 cluster attachment screws. See Figure 13-3.
NOTE: Retain removed hardware for re-installation.
