INSTRUMENTS (AND AVIONICS) / INSTRUMENTS AND AVIONICS GENERAL MAINTENANCE 13-37
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 13
TASK INSTRUCTIONS:
1. Remove center console bucket. (See “Center Console Bucket Removal” on page 8-5.)
2. Access the hour meter. (See “Throttle Handle and Bezel Removal” on page 8-10.)(See “Throttle
Handle and Bezel Installation” on page 8-13.)
VERIFICATION METHOD:
The procedure is complete when you have removed and installed the hour meter.
