13-38 INSTRUMENTS (AND AVIONICS) / ANNUNCIATOR PANEL
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 13
13.4 Annunciator Panel
13.4.1 Annunciator Panel Description
The annunciator panel is located near the center of the insturment console between the primary and
secondary instrument clusters. The upper row indicators are warning lights, which illuminate in red to
draw pilot attention to act on critical safety of flight issues. The three warning lights are PURGE BILGE,
LAND AIRCRAFT, and SECURE WING/TAIL. The bottom row indicators are caution lights, which illu-
minate in amber to draw pilot attention to aircraft system status or failures that may warrant action.
The four caution lights are BATTERY, FUEL PRESS, ENGINE, and ALTERNATOR. For detailed
meaning of, and responses to, the annunciator lights. (See “Annunciator Panel Diagnostic” on page
13-9.)
13.4.2 Annunciator Panel Diagram/Schematic
FIGURE 13-7
ANNUNCIATOR PANEL
13.4.3 Inspection Instructions
13.4.3.1 Annunciator Panel Function
The following section contains information needed to test annunciator panel function.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
Owner/Pilot
Task Specific Training Required
No
Special Tools Required
None
TEST
ENGINE ALTERNATOR
FUEL PRESSBATTERY
LAND
AIRCRAFT
SECURE
WING/ TAIL
PURGE
BILGE
