LANDING GEAR / TROUBLESHOOTING 14-5
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 14
14.3 Troubleshooting
14.3.1 Check Landing Gear Extended Position
The following section contains the information required to evaluate the rigging of the landing gear
components in the extended position.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
Inclinometer
Wing Jack Point Adapter—ICA009750
Parts Required
None
Aircraft System and Number
11—Landing Gear
Consumables
None
TASK INSTRUCTIONS:
1. Remove the Aft Bulkhead Baggage Panel (See “Removal and Installation of Inspection Panels
and Fairings” on page 3-34.) to access the landing gear control systems.
2. Jack the aircraft using the built-in jack points. (See “Empty Weight and CG Measurement While
on Jackpoint Scales” on page 3-32.)
3. Extend the landing gear to its deployed position.
4. With the aircraft jacked and level, zero a digital protractor along the longer of the two pushrods.
