LANDING GEAR / TROUBLESHOOTING 14-7
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
Special Tools Required
Wing Jack Point Adapter—ICA009750
Parts Required
None
Aircraft System and Number
11—Landing Gear
Consumables
None
1. Remove the Aft Bulkhead Baggage Panel (See “Removal and Installation of Inspection Panels
and Fairings” on page 3-34.) to access the landing gear control systems.
2. Jack the aircraft using the built-in jack points. (See “Empty Weight and CG Measurement While
on Jackpoint Scales” on page 3-32.)
3. Initiate gear retraction.
4. Verify landing gear indication moves to “In Transit” while actuators are working.
5. Once stopped, verify blue landing gear up indication has been obtained.
6. View the actuation process and verify the main landing gear connects with the up-stop. The
up-stops are located near the wheel well, underneath the Seawings™ platform.
7. Verify that the landing gear has fully retracted and the nose gear doors have withdrawn
completely to provide a smooth closed outer surface.
8. Extend landing gear.
9. Turn off master switch.
10. Replace Aft Bulkhead Baggage Panel.
11. Lower the aircraft.
VERIFICATION METHOD:
Verify that each check is passed successfully.
