LANDING GEAR / AFT NOSE LANDING GEAR DOOR 14-89
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 14
9. Prepare forward RH bellcrank by pressing pin into bellcrank so that the pin is flush with the aft
face of the bellcrank. Prepare the forward LH bellcrank so that it is a mirror image of the forward
RH bellcrank.
Qty Item No Part No
1(10)97395A485
1(19)ICA010035
1(23)ICA010059
