PLACARDS AND MARKINGS / PLACARDS AND MARKINGS GENERAL MAINTENANCE 15-11
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
15.2.2.5 Wing Release
Located on both wing tips near the trailing edge on top and bottom surfaces (total of four locations).
15.2.2.6 Wing Lock
Located on bottom, center wing near wing fold joint forward of the locking handle. There are two per
aircraft—one on the right side and one on the left side.
15.2.2.7 Tire Pressure
Located on main and nose landing gear legs.
