15-12 PLACARDS AND MARKINGS / PLACARDS AND MARKINGS GENERAL MAINTENANCE
ICON A5 / MAINTENANCE MANUAL CHANGE C1
15.2.2.8 Keep Static Port Clear
Located on both sides of the vertical tail.
15.2.2.9 Aircraft Data Plate
Located on the left rear of the empennage below the vertical tail.
NOTE: Serial number is for illustration only. Your aircraft serial number will
be different.
15.2.2.10Registration Numbers
Located on the left and right sides of the empennage.
NOTE: Registration numbers are for illustration only. Your aircraft registra-
tion number will be different.
15.2.2.11 Light Sport
Located on right and left sides of aircraft nose.
NOTE: Color shown for reference only.
