PROPULSION / ENGINE 16-5
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 16
16.1.2 Diagram/Schematic
FIGURE 16-1
VIEW LOOKING DOWN, AFT, RHS (OIL TANK NOT SHOWN)
CYL.1
CYL.3
ENGINE MOUNT
AIRBOX
FUEL RAIL
FUEL RETURN LINE
FUEL SUPPLY LINE
THERMOSTAT-RADIATOR
INLET COOLANT HOSE
PROPELLER SHAFT
GEARBOX COVER
FUEL RAIL
COVER
OIL TANK-ENGINE
OIL HOSE
INTAKE MAINFOLD
INTAKE MANIFOLD
EXHAUST
(TO EXHAUST ASSY)
