16-6 PROPULSION / ENGINE
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 16
FIGURE 16-2
VIEW LOOKING DOWN, FWD, LHS (OIL TANK NOT SHOWN)
CYL.4
CYL.2
OIL FILTER
COOLANT OVER-FLOW
BOTTLE
STARTER HARNESS
SPARK PLUG
FUEL SUPPLY LINE
FUEL RAIL COVER
COOLANT EXPANSION TANK
TEMPERATURE SENSOR
PRESSURE SENSOR
EXHAUST
(TO EXHAUST ASSY)
IGNITION
COIL
