PROPULSION / ENGINE 16-75
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 16
FIGURE 16-47
OIL TANK INSTALLATION. SOME COMPONENTS NOT SHOWN FOR CLARITY.
VERIFICATION METHOD:
The task is complete when the oil tank has been removed.
FITTING, HOSE END
OIL THERMOSTAT
PLENUM AIR BOX
OIL TANK IN FITTING
TANK-THERMOSTAT HOSE
