16.1.8.3.2 Install Oil Tank
Use the following instructions to install the oil tank.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
TY24MX (CABLE-TIE, NYLON 6-6, 30LB)
J1508F-88 (CLAMP, WORM DRIVE, .50X5.50)
Aircraft System and Number
13—Propulsion
Consumables
None
1. Secure the oil tank to the oil tank mount in the orientation shown in Figure 16-47 using 2X CLAMP,
WORM DRIVE. Torque to 25-30 in-lbs.
NOTE: The oil tank must maintain a minimum clearance of .25 inches from
the firewall.
2. Remove any plugs and install oil hose at thermostat. Torque to 150-250 in-lbs.
3. Remove plugs and install oil return hose at “IN” port of oil tank. (See Figure 16-14.) Torque B nut
to 300-350 in-lbs if using Method A or to 290-330 in-lbs if using Method B. (See Figure 16-10.)
CAUTION: Ensure a back-up wrench is used on the oil tank fitting while
torqueing. Damage to oil tank may occur if it’s not used.
4. Secure reservoir-thermostat hose to the cable tie mount using a CABLE-TIE.
5. Secure purge hose to the engine mount using a CABLE-TIE. (See Figure 16-14.)
