PROPULSION / PROPELLER 16-93
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 16
FIGURE 16-58
PROPELLER INSTALLATION—VIEW LOOKING AFT, LHS
16.2.3 Troubleshooting
16.2.3.1 Propeller Assembly
Instructions for assembling the Sensenich propeller prior to installation onto the Rotax engine.
TASK INFORMATION:
Type of Maintenance
Line
PROP FLANGE
ROTAX 912iS
2X COOLING FAN HALF
SPINNER DOME
6X #10-32 SCREW
(MAY HAVE WASHERS USED
FOR BALANCING PROPELLER)
PROPELLER ASSY
PROPELLER EXTENSION
6X #5/16-24 NUT
6X #5/16-24 BOLT
6X BUSHING, ROTAX
