17.4 Flaps
17.4.1 Maintenance Instructions
17.4.1.1 Flap Surface Removal
Use the following procedure to remove the flap surface from the wing.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
14—Wing
Consumables
None
NOTE: There are two styles of flap hinge pin. One style retains the pin with
snap rings and the other style uses cotter pins. Remove the flap
pins by removing snap rings (XSC-113) or cotter pins
(MS24665-151) as needed.
NOTE: Avoid operating the flap system with flaps removed. The free end
of the actuation pushrods could snag and cause damage.
TASK INSTRUCTIONS:
1. Extend the flaps to 30°.
2. Support the flap with a cradle from below or with a helper.
3. Remove the AN4C13A bolt, MS21043-4 nut, and two NAS1149C0432R washers that attach the
flap pushrod to the flap surface of the affected flap.
