17-20 WING / FLAPS
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 17
4. Remove the hinge pins and 95630A460PTFE washers from all three hinges of the affected flap.
5. Remove the flap from the wing.
VERIFICATION METHOD:
The procedure is complete when the flap has been removed from the wing.
RELATED INFORMATION:
"Flap Hinge Repair Procedure" on page 17-22
17.4.1.2 Flap Surface Installation
Use the following procedure to install the flap surface on the wing.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
14—Wing
Consumables
None
NOTE: On new installations, the version of hinge pin that is retained with a
cotter pin should be used.
TASK INSTRUCTIONS:
1. Verify that the flaps are still commanded to the 30° position.
2. Support the flap with a cradle from below or with a helper.
3. Align the hinges flap to wing and install the washers and pins at each of the three hinge locations
per flap as shown in Figure 17-2. To minimize the gap between hinge elements, use
95630A460PTFE washers as needed but with a minimum of one on each side of the flap hinge
