ICON A5 - Page 754

17-22 WING / FLAPS
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 17
RELATED INFORMATION:
"Inspect Flap Rigging" on page 9-65
"Flap Hinge Repair Procedure" on page 17-22
17.4.1.3 Flap Hinge Repair Procedure
If excess free play is identified upon inspection of the flap hinges, perform the following procedure.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Re
None
Parts Required
None
Aircraft System and Number
14—Wing
Consumables
LOCTITE
®
EA 9394
TASK INSTRUCTIONS:
1. There are two styles of flap hinge pin. One style retains the pin with snap rings and the other style
uses cotter pins. Remove affected flap pins by removing snap rings (XSC-113) or cotter pins as
needed.
2. Remove and inspect pins by measuring the minimum pin diameter with a mircrometer or caliper.
If they are less than .0175”, are loose or appear worn, replace.
