WING FOLD MECHANISM / WING FOLD MECHANISM GENERAL MAINTENANCE 18-11
CHANGE C0 ICON A5 / MAINTENANCE MANUAL
18.3 Wing Fold Mechanism General Maintenance
18.3.1 Wing Fold Roll Bellcrank Roller Replacement
The roll control system loads pass across the wing fold joint through two intermeshing bellcranks. The
bellcrank on the outboard side of the joint has a ball bearing that serves as a roller to guide the two
bellcranks together during the wing fold operation. Perform the procedure below to replace this
bearing.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
15—Wing Fold Mechanism
Consumables
MOLYKOTE™
