19-6 ICON PARACHUTE SYSTEM (IPS) / TROUBLESHOOTING
ICON A5 / MAINTENANCE MANUAL CHANGE C1
tion handle). Compare color, brightness, and texture. Replace activation line if there is any
variation between these two sections.
f. Check security of the activation handle mounting plate.
g. Visually inspect the activation handle for damage or abnormalities.
h. Confirm text on the placards is legible.
3. If any discrepancies are detected in the preceding instructions, the discrepancies must be recti-
fied in order to consider the instruction compete. If all instructions are not completed the para-
chute system must be marked “Inoperative”.
VERIFICATION METHOD:
Verify there are no cracks or other anomalies.
RELATED INFORMATION:
"Removal and Installation of Inspection Panels and Fairings" on page 3-34
"Cockpit Panels Removal and Installation" on page 3-36
