ICON PARACHUTE SYSTEM (IPS) / PARACHUTE PACKAGE 19-7
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
CHAPTER 19
19.4 Parachute Package
19.4.1 Parachute Package Description
The IPS parachute package is comprised of deployment bag, BRS 601 rocket lanyard and retaining
straps. The entire package, installed in the parachute bay, is enclosed under the Egress Panel. The
parachute package contains a round, non-steerable parachute used for recovery of the aircraft and its
occupants.
19.4.2 Parachute Package Diagram
FIGURE 19-1
PARACHUTE PACKAGE INSIDE OF PARACHUTE BAY
19.4.3 Inspection Instructions
19.4.3.1 Parachute Package Inspection
Use the following tasks to inspect the BRS parachute package.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
