19-34 ICON PARACHUTE SYSTEM (IPS) / ACTIVATION SYSTEM
ICON A5 / MAINTENANCE MANUAL CHANGE C1
CHAPTER 19
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
16—ICON Parachute System (IPS)
Consumables
None
TASK INSTRUCTIONS:
1. Inspect activation cable line from the activation handle to the rocket for evidence of cracking,
kinking, or chaffing.
WARNING: At no time pull or force the cable-rocket could be activated.
2. Compare the section of the activation line that is routed through the engine bay against a section
that is in a relatively cooler area (for example fwd. of the bulkhead near the activation handle).
Compare color, brightness, and texture. Replace activation line if there is any variation between
these two sections.
3. Check security of the activation handle mounting plate.
4. Visually inspect the activation handle for damage or abnormalities.
VERIFICATION METHOD:
Verify there is no chafing, discoloration, damage, or other anomalies.
RELATED INFORMATION:
"Removal and Installation of Inspection Panels and Fairings" on page 3-34
"Cockpit Panels Removal and Installation" on page 3-36
19.7.4 Maintenance Instructions
19.7.4.1 Activation System Installation
Use the following tasks to install the parachute activation system.
TASK INFORMATION:
Type of Maintenance
Line
