iPECS eMG80 & eMG800 & UCP
Feature Description and Operation Manual Issue 1.6
112
Conditions
1. The eMG has two External Control Contacts, one each located on the Miscellaneous
connector of the KSU and EKSU.
2. The UCP100 has a single External Control Contact while the UCP600 and UCP2400
each have four (4) External Control Contacts.
3. The Door Open feature dial code is based on the assigned External Contact as below:
 External Contact 1 = “#*1”
 External Contact 2 = “#*2”
 External Contact 3 = “#*3”
 External Contact 4 = “#*4”
4. The contacts are rated at 1 amp, 24 VDC.
5. A station will receive error tone if not allowed access to the Door Open feature (PGM
113-Button 24-2) or in Station Data Common Attributes.
Programming
Keyset Admin.
SYSTEM External Contact Control (PGM 168)
Door Open Timer (PGM 181-Button 5)
STATION
Door Open (PGM 113-Button 24-2)
STATION
Web Admin.
Common Attributes

Door Open
SYSTEM DATA External Control Contacts
System Timers

Door Open Timer
Related Features
 LBC (Loud Bell Control)
 Alarm Signal/Door Bell
Hardware
 External Control Contact connected to a door-lock release mechanism.
