4.2 Caller ID Mode
Description
The Caller ID signals for analog CO Lines varies from region to region. To support these
differences, each analog CO Line is assigned the type of Caller Id signal provided from the CO
Line. The Caller Id signal type can be configured as:
 FSK
 DTAS FSK
 DTMF
 Russia-CID
Operation
Conditions
Operation of this feature is either automatic (when programmed) or by Web Admin.
1. Caller ID is provided from analog CO Lines after the first ring signal. To detect Caller
ID, ‘ICLID Ring Timer’ should be set in UCP.
Programming
Keyset Admin.
CO/IP
CO Additional Attribute - CID setting (PGM 148-Button 1)
CO LINE DATA
Web Admin.
CID/CPN Attributes  CID Mode
Analog Attributes

ICLID Ring Timer
Related Features
Hardware
