5.20 Serial DSS/BLF Console
Description
The iPECS IP & LDP Phones can be connected to a DSS/BLF Console to provide additional
Flexible button for your use. This can be particularly useful for an Attendant or Secretarial
answering position.
The Console is attached to the phone through a serial cable connection and thus does not use
another station port on the system. For more information about DSS models except the below,
ask your dealer.
 LIP-8012DSS-12 button Console with paper button designation label.
 LIP-8012LSS-12 button Console with LCD for button designation label.
 LIP-8048DSS-48 button Console with paper button designation label.
 LIP-8040LSS-40 button Console with LCD with Triple color LED.
 LIP-9012DSS has 12 flexible buttons with tri-color LED. The DSS button kit
uses a paper label for the button designations.
 LIP-9024DSS has 24 flexible buttons with tri-color LED. The DSS button kit
uses a paper label for the button designations.
 LIP-9024LSS has 12 flexible buttons with tri-color LED. The LSS button kit
uses an LCD for the button labels and has two flexible button pages to
represent 24 total flexible buttons. The two lower buttons control the page view.
The page button LED will flash when there is new activity under a button on
the page. You can press the page button at any time to change the flexible
button page view.
 LIP-9048DSS has 48 flexible buttons with tri-color LED. The DSS button kit
uses a paper label for the button designations.
 LDP-7048DSS-48 button Console with paper button designation label.
 LDP-9048DSS-48 button Console with paper button designation label.
 LDP-9248DSS-48 button Console with paper button designation label.
The DSS models employ a paper label strip to designate the function of each button. The LSS
model employs an LCD to designate the button function. The designation for a button on the LSS
model employs standard designations such as STA xxx for a {DSS/BLF} button but can be
modified in the system database to meet your needs.
With some restrictions you may equip your phone with up to four (4) Serial Consoles. For
installation details, refer to the Hardware Description and Installation Manual or Quick Installation
guide of Each phone.
Operation
iPECS IP & LDP Phone
Flex buttons on the Serial Console operate the same as the buttons on the phone
