3.3 Intercom (ICM) Call
Description
A non-blocking ICM is available to all stations only in UCP system. You may place an intercom
call to other stations in the system by dialing applicable digits as defined in the Station Numbering
Plan.
Operation
iPECS IP & LDP Phones
1. Lift the handset or press the [SPEAKER] button to receive ICM dial tone.
To place an intercom call
2. Dial station number or press the {DSS/BLF} button.
3. For ring-back tone, await answer or, for Intercom splash-tone, speak and await answer.
SLT
1. Lift the handset to receive ICM dial tone.
To place an intercom call
2. Dial the station number.
3. For ring-back tone, await answer or, for Intercom splash-tone, speak and await answer.
Conditions
1. Intercom dial tone will time-out if action is not taken within Dial-Tone Time or if the time
between digits exceeds the Inter-digit Timer. Error tone is received should a time-out
occur.
2. ICM Dial tone is removed after dialing the first digit.
3. If the called station is busy, Intercom Busy tone is provided for the Busy Tone time
then, error tone is sent by the system. You may disconnect from the call or activate a
feature such as Message Wait/Callback prior to the time-out.
4. With your iPECS IP and LDP Phone, you can place consecutive Intercom calls without
the need to regain ICM dial tone (no need to hang-up) between calls; simply presses
another {DSS/BLF} button.
5. An Intercom call to a station in the HF answerback or Voice Announce mode (H or P
Intercom Signaling Mode) is not considered answered unless the called user lifts the
handset or presses the [SPEAKER] button (goes off-hook).
Programming
Keyset Admin.
STATION
Prime Line (PGM 113-Button 7)
SYSTEM
ICM Dial Tone Timer (PGM 181-Button 6)
