2.72 Registration & Fractional Module Tables for UCP
Description
Normally, local iPECS devices can register with the system only when the “Registration Switch”,
3rd Dip switch on the UCP module, is ON. In this state, the system will allow any local iPECS
device to register, providing a convenient “plug & play” initial installation. After initial installation,
the Registration Switch is placed in the OFF position, disabling registration of additional local
devices.
To eliminate the potential for unintended device registration, particularly where multiple systems
exist on the same LAN, the system can be programmed to allow local device registration
employing MAC addresses. Using the defined MAC address registration, the system allows a
device with a matching MAC address to register regardless of the Registration Switch position.
Three tables are provided to enter MAC addresses. The System & Device IP Plan allows entry of
two MAC address ranges. Any device with a MAC address in either of the ranges will be
permitted to register with the system.
The second is the Registration Table. This Table permits entry of five MAC addresses and the
number of channels to be registered for each device. Entering the MAC address permits the
device to register with the system regardless of the Registration Switch position. The number of
channels available to the device is limited to the number of channels entered in the Table. This
function is commonly used to limit the number of channels available over an E1/T1 or PRI ISDN
circuit (Fractional T1 line).
The third is Device Login  Remote Device Registration that allows entry of the MAC address of
a remote phone or gateway Module as well as the Nation code and Zone. During registration, the
system will compare the MAC address received from the remote device and, if matched, will
permit registration of the device. Once the device is registered, the data for the device is placed in
the appropriate locations and the data is removed from the Remote Device Registration Table.
Operation
Conditions
Operation of registration is automatic based on the system database and Registration Switch
position.
Programming
SYSTEM ID
&NUMBERING PLANS
System& Device IP Plan First MAC Range, Second MAC
Range
TABLES DATA
Registration Table
DEVICE LOGIN
Remote Device Registration
Related Features
Hardware
