1.4 Buttons & Term Variations
The eMG supports proprietary digital and IP phones. The proprietary models include the LDP-
7000 series, LDP-9000 series, LDP-9200 series, LIP- 7000 series, LIP-8000/8000E series, and
LIP-9000 Series, and LIP-907x series. Each series employs similar but slightly different
designations for the buttons. Details of the buttons on your phone are provided in the User
Guide. For the purposes of this manual, several of the designations may be used. For
example, the button to handle messages is called either [MSG], [CALL BK], or
[MESSAGE/CALLBACK]. Note the fixed button names are enclosed in brackets ‘[ ]’ and Flex
buttons are enclosed in braces ‘{ }’. In addition, some buttons have dual functions; the
[HOLD/SAVE] button places your active call on hold and stores entries you make when
assigning Flex buttons.
The description, operation and conditions attempt to use common terms such as “Voice Mail” or
“outside Line” so that a novice installer can understand the contents. The Programming and
Hardware sections however employ terms specific to the iPECS system as used in the respective
manual such as “VSF” (used for voice mail) and “CO/IP lines” for outside Lines.
Note the feature code is based on
Flexible numbering plan 2
in Operation part. First check your
numbering plan ‘System ID (100)’ and for the detailed feature code about the numbering plan,
refer to Appendix on Administration & Programming manual.
1.5 eMG80 Expansion
The maximum number of TDM port can be expanded in BKSU-IE/AE. For more detailed
information about KUSIE & AE, refer to Hardware Description and Installation Manual.
1 Connect Expansion cable between BKSU-IE/AE of master and slave.
To install
2 Set TNET program.
Conditions
1 IP device should be registered to master system.
2 A WTIB can be installed in master system, not in slave.
3 ISDN clock is synchronized only in master system, so stable clock should be provided by
ISDN line of master system, not in slave.
4 eMG80N-EXPM should be installed in master system.
5 eMG80N-EXPS should be installed in slave system.
