6.11 DSS/BLF Consoles
Description
Two types of DSS/BLF Consoles are available and can be used with an Attendant station Serial
Consoles and standard Consoles. For details on the Serial console operation, refer to section
‘Serial DSS/BLF Console’.
The system allows an unlimited number of standard DSS/BLF Consoles to be installed in the
system. Up to three (3) standard DSS Consoles may be associated with a station connected to
the system. However, the maximum of DSS consoles may be different according to the models of
phone. Each button on the console can be assigned as an outside Line, DSS/BLF or feature
button.
For ease of programming, each console is assigned to a button “map” in the system database.
The Administrator or user may then change individual Flex buttons as desired. Operation of the
DSS/BLF Console Flex buttons is the same as Flex buttons on the iPECS IP and LDP Phones.
Operation
Conditions
1. Each DSS Console is assigned to operate in connection with a specific station.
2. There is no limit to the number of DSS Consoles in a system beyond the basic system
capacities. The DSS Console employs a station number in the system.
3. Assignments for the DSS button maps are detailed in the iPECS Administration &
Programming manual. Note that the individual button assignments can be changed as
with iPECS IP and LDP Phone Flex buttons.
Table DSS/BLF button maps
MAP 1
Flex 1 Atd Override
Flex 2
All Call Page
Flex 3 Call Park 01
Flex 4-
Station Group 1
Flex 5 Camp-On
Flex 6
Int All Call Page
Flex 7 Call Park 02
Flex 8
Station Group 2
Flex 9 Monitor key (Release)
Flex 10
Ext All Call Page
Flex 11 Call park 03
Flex 12
Station Group 3
