Conditions
1. The maximum number of Serial Consoles supported in an eMG80 system is 100 and
no more than 60 can be the LSS model and in eMG800/UCP system is 500 and no
more than 200 can be the LSS Model.
2. The iPECS IP Phone model LIP-8004 does not support a Serial DSS/BLF Console.
3. The LIP-8048DSS must always be powered by external adaptor available from
Ericsson-LG Enterprise.
4. An iPECS IP Phone can only provide power to two Serial Consoles, the remaining
Consoles must be powered by the external adaptor
5. Linked pair secondary station cannot have a Serial Console.
6. When configuring Flex buttons from the phone, the Serial Console Flex buttons are not
used, use the [VOL UP]/[VOL DOWN] buttons to scroll. For example, when you press
the [VOL UP] button the Flex buttons on the phone will represent the first buttons on
the first Console. Note that even though a Console may have only 12 buttons, the
system allocates 48. When programming Flexible button labels for an LSS, the1st
Console starts from button 49, the 2
nd
starts from button 97, the 3rd Console starts
from button 145, 4th starts from button 193.
7. As a default, the 48 button Console is assigned with button Map 1 to 4 depending on
the position of the Console. The 12 button Consoles are not assigned a map.
8. If DSS configuration is changed and the phone restarts, programmed DSS data is
initialized from the changed DSS.
9. While idle, the [VOL UP]/[VOL DWN] buttons control the contrast of the LCD of both
the iPECS IP Phone and the LSS model serial.
10. Your station must be enabled to employ a Serial Console, if not enabled, any
connected console will not function.
11. The LIP Phones can also be associated with the standard LIP-8040LSS-40 button
Console with LCD designations. A maximum of nine (9) such consoles can be
associated with a station.
12. LDP-7048DSS-48 button Console with paper button designation labels may be used
with the LDP 7000 series phones. LDP-9048DSS-48 button Console with paper button
designation labels may be used with an LDP 9000 series phone.
Programming
Keyset Admin.
STATION
Serial DSS Usage (PGM 111 –Button 21)
Flex Button Assign (PGM 115)
Serial LSS Label Edit (PGM 129)
STATION DATA
Web Admin.
Terminal Attributes Serial DSS Usage
Flexible Buttons

LSS Label
Related Features
Hardware
 iPECS IP & LDP Phone with Serial DSS/BLF Console
