6.11Oversampling
Encoder signal oversampling optimizes the accuracy of resolver and SinCos
signals. This function can only be used, if necessary, for low-track SinCos encoders
and resolvers; using it for high-track SinCos encoders is not permissible.
ID Index Name Unit Description
1956  CON_ACT_Ovrs  Encodersignaloversampling.Thisfunction
appliesonlytoresolverandSinCossignals
1956 0 active  Switchforactivatinganddeactivatingthe
function
1956 1 pmeas  Thepercentagemeasuringtimeforoversampling
dependentonthesamplingtime.
1956 2 filtershift  Limitfrequencyfortheoversamplingfilter
1956 3 sourceselect  Signalsourceforoversampling
1957  CON_ACT_Ovrs_Tracks  Oversampledtracksignals
1957 0 Track_a  
1957 1 Track_b  
Table 6.38: Oversampling parameters
NOTE
l Whenoversamplingisenabled,insteadofthenormalA/Dsignals
theoversampledsignalsfortheencoderspecifiedinparameter
P 1956[3] - sourceselectareused.Inthecaseofhigh-track
SinCosencodersinparticular,thelowlimitfrequencyofthe
oversamplingfiltersmayresultinquadranterrors.Ifthe
oversamplingunitsareused,itmustalwaysbecertainthatthe
encoderdoesnotdramaticallyexceedthespecifiedlimit
frequencies.
l Beforeusingoversampling,consultwithyourprojectsupervisoror
theKEBAHelpline.
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
106
6 Encoder
6.12Multi-turnencoderasasingle-turn
encoder
By way of parameters P548[0] - ENC_CH1_MTEnable = 1 (for Channel 1) and
P585[0] - ENC_CH3_MTEnable = 1 (for Channel 3) a multi-turn encoder can be run
as a single-turn encoder. This function is used primarily for testing purposes.
