6.7.2AbsolutevalueinterfacesX8
The following absolute value interfaces will be available at encoder channel Ch3
depending on the X8 option being used.
l CyclicalSinCoswithSSIone-timereadingviaX8option:SINCOS_V2(10)-
2ndSinCosencoder(V2)
l CyclicalSinCoswithEnDatone-timereadingviaX8option:SINCOS_V2(10)
-2ndSinCosencoder(V2)
l CyclicalSSIviaX8options:SINCOS_V2(10)-2ndSinCosencoder(V2)or
SSI_ECSIM(3)-SSIencodersimulation
l CyclicalEnDatviaX8option:SINCOS_V2(10)-2ndSinCosencoder(V2)
l CyclicalHDSLviaX8option:HDSL(15)-HIPERFACEDSL®option
(ServoOnejunioronly)
See also table in Section "Channel 3: Interface X8 (optional)" on page 78.
They can be selected with P507[0] - ENC_CH3_Sel and P570[0] - ENC_CH3_Abs.
For more details, see Section "Main parameters for encoder channel Ch3" on page
82.
6.7.3BiSSX8
BiSS interfaces are not supported on encoder channel Ch3!
6.7.4EnDat(cyclical)X8
Ch3: ENDAT(4) - Cyclical EnDat (2.1 or 2.2)
As the EnDat functionality of the parameters for encoder channel Ch3 is
predominantly identical to that of the parameters for encoder channel Ch1, it is
recommended to read the description for the Ch1 encoder channel parameters (see
Section "EnDat (cyclical)X7" on page 62).
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
84
6 Encoder
The software versions required to run the EnDat interface are the standard software
versions for the ServoOne and ServoOnejunior.
NOTE
l PleasenotethelimitationsthatapplywhenrunningEnDatand
SSIencoders(seeSection"LimitingforEnDatandSSI"onpage
52).
ID Index Name Unit Description
507 0 ENC_CH3_Sel=4 =ENDAT(4)
573 0 ENC_CH3_MultiT NumberofMultiTurnbits(absoluteencoder)
574 0 ENC_CH3_SingleT NumberofSingleTurnbits(absoluteencoder)
584 0 ENC_CH3_MTBase Definitionofpointofdiscontinuityinmulti-turn
range
585 0 ENC_CH3_MTEnable 1:UseMulti-turnencoderasasingle-turn
encoder
636 0 ENC_CH3_CycleCount Positionencodersamplingcycle(nx125µsec)
600 0 ENC_CH3_Position inc Positionencoderchannel3
583 0 ENC_CH3_
DigitalResolution
nm Lengthofoneincrement(linearabsoluteencoder)
640 0..29 ENC_ENDAT EnDatadditional(additionalinformation)
Table 6.23: Channel 3 encoder configuration (X8) - EnDat (cyclical) parameters
6.7.5HallsensorX8
Encoder channel Ch3 does not support Hall effect sensors!
