NOTE
l FiltercapacitanceP 2901[1] - C_Filtisspecifiedasthe
capacitancevalueofthecapacitorswhenusingadelta
configuration!Inordertocalculatethecapacitanceperphaseas
perthecircuitdiagramabove,thedevicewillinternallymultiply
thevalueby3(delta-wyetransform).Ifthecapacitorsare
connectedinawyeconfiguration,orifthecapacitanceofthe
single-phaseequivalentcircuitisknown,thecorresponding
capacitancevaluemustfirstbedividedby3andthenenteredinto
theparameter.
 
5.7.4Scopesignals
ID Index Name Unit Description
2500 0 isdpre_SinFilt A Calculatedfiltercapacitorcurrentdcomponents
(isd
Cf
intheformulaabove)
2501 0 isqpre_SinFilt A Calculatedfiltercapacitorcurrentqcomponents
(isq
Cf
intheformulaabove)
2502 0 usdmot_SinFilt V Calculatedmotorterminalvoltagedcomponents
2503 0 usqmot_SinFilt V Calculatedmotorterminalvoltageqcomponents
Table 5.11: “Motor filter” scope signals
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
50
5 Motor
