Keba ServoOne User Manual

8.5.15Method(33)and(34):withzeropulse
8.5.15.1Method(33):Leftwardtraveldirection
The zero pulse corresponds to the first zero pulse to the left.
Image 8.60: Homing with zero pulse
8.5.15.2Method(34):Rightwardtraveldirection
The zero pulse corresponds to the first zero pulse to the right.
Image 8.61: Homing with zero pulse
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
266
8 Motion profile
8.5.16Method(35)
The actual position corresponds to the reference point.
Image 8.62: The actual position corresponds to the homing point
