Remote RMX-3200 Version 5.2x Configuration Guide
Configuring Event Correlations: Correlation Expression Components
14-3
Correlation Expression Components
The following illustrates a basic expression configuration:
Figure 14-1 Correlation Expression Example
A Term in a correlation expression is used to test the current state of an originator.
The Term consists collectively of the following elements:
 Originator Type, which is one of the Remote RMX-3200 event originator types.
The type can also be
correlation, which refers to other event correlations.
 Instance value, which is one of the valid instances for the specified type, for
example,
0/1, 2.
 State, which is a valid state for the originator. In the case of a measurement, the
state may be a relational operator and a numeric value (for example,
< 48 or >
95).
Originator Types and States
Table 14-1 lists the types of originators that are valid for the correlation expressions,
the associated events that are valid as a state comparison and those originators that
can be used as multi-originators. Multi-originators must have either an
any or an all
operator before the multiple instance token. See
Operators on page 14-4 for details.
Table 14-1 Event Originator Types and States
Term Operator
Term
OriginatorType Instance State and OriginatorType Instance State
Originator Type Valid State Events Multi Support
analog
high, in-band, input-
saturated, loss of signal, low
yes - point ranges
input
close, open yes - point ranges
output
close, open yes - point ranges
correlation
false, true no
measurement
high, in-band, input-
saturated, loss of signal,
low, <, <=, =, >=, >, !=
yes - point ranges
