Remote RMX-3200 Version 5.2x Configuration Guide
Configuring Controllers and Interfaces: Configuring T1/E1 Line Settings
7-3
Configuring T1/E1 Line Settings
To configure the T1/E1 line settings:
1. At the main prompt, configure the line buildout for controller
serial wan/1 as -
7.5db:
config controller serial wan/1 buildout -7.5db
Notes: On DAC Remote RMX-3200 models, serial wan/2 buildout is
automatically configured based on the serial wan/1 buildout setting. This
causes the sum of the line buildout for serial wan/1 and serial wan/2 to
not exceed the maximum allowable buildout. In the event of an Remote
RMX-3200 system failure (in which case internal relays provide T1
continuity across Remote RMX-3200) the automatic buildout setting
assures that the line buildout will not exceed the maximum allowable
level.
Buildout is not configurable on E1 Remote RMX-3200 models.
2. Configure the line framing format as
d4 for a T1 serial controller or crc4 for an E1
serial controller:
config controller serial wan/1 framing d4
config controller serial wan/1 framing crc4
3. Configure the bit-level encoding method as b8zs:
config controller serial wan/1 linecode b8zs
4. (Optional) Disable the T1 loopback detection.
config controller serial wan/1 loop-detect disable
Note: The loopback detection option is not available on E1.
In this scenario, you will:
Set the WAN line buildout value
Set the WAN line framing format
Set the WAN line bit-level encoding method
Disable loopback detection.
