Kentrox RMX-3200 - Configuring a Measurement Table Entry for a Temperature Sensor

Remote RMX-3200 Version 5.2x Configuration Guide
Configuring Measurements and the Measurement Table: Configuring a Measurement Table Entry for a
Temperature Sensor
16-5
Configuring a Measurement Table Entry for a Temperature
Sensor
To configure a measurement table entry for an external temperature sensor:
1. At the main prompt, configure measurement table entry
ExtTemp1 with
description
External temperature sensor:
config meas-table entry ExtTemp1 description External temperature
2. Configure category name envAlms:
config meas-table entry ExtTemp1 category envAlms
3. Configure measurement units Degrees F:
config meas-table entry ExtTemp1 units Degrees F
4. Configure network element name sensorUnit:
config meas-table entry ExtTemp1 ne-name sensorUnit
5. Configure the normal range for measurement values:
config meas-table entry ExtTemp1 band 65 80
6. Configure the maximum measurable value:
config meas-table entry ExtTemp1 maximum 130
7. Configure the minimum measurable value:
config meas-table entry ExtTemp1 minimum -30
8. Configure the originator for this measurement:
config meas-table entry ExtTemp1 originator analog 0/4
9. Enable the measurement table entry:
config meas-table entry ExtTemp1 enable
In this scenario, you will:
 Configure a measurement table entry with name and description
 Configure a category name
 Configure measurement units
 Configure a network element name
 Configure the normal (in-band), maximum and minimum values
 Configure the originator for a measurement table entry
 Enable the measurement table entry
