Configuring Discrete I/O Points on an Expansion
Peripheral
Display points on an expansion peripheral are configured using the same commands
that configure and display Remote RMX-3200’s on-board I/O points.
To configure discrete I/O points for the discrete expansion peripheral:
1. Configure default alarm entries for discrete input
2/2:
config discrete input 2/2 alarm-default
2. Enable discrete input 2/2:
config discrete input 2/2 enable
3. Configure description Output 12 for discrete output 2/12:
config discrete output 2/12 description Output 12
4. Enable discrete analog 2/3
config discrete analog 2/3 enable

Note: For more information on discrete analog input settings, refer to section
Configuring an Alarm Entry for a Temperature Sensor on page 15-4.
5. (optional) Verify that the discrete I/O points have been configured properly:
show discrete inputs 2/2
The display will look similar to the following for the discrete input:
show discrete outputs 2/12
In this scenario, you will:
 Configure a default alarm entry for a discrete input point on a peripheral unit
 Enable the discrete input point on the peripheral unit
 Configure a description for a discrete output on the unit
 Enable a discrete analog point on the unit.
(Dub)>show discrete inputs 2/2
ID - 2/2
Description -
State - enable
Value - open
(Dub)>
