Remote RMX-3200 Version 5.2x Configuration Guide
Configuring the Peripheral Management Subsystem: Configuring Discrete I/O Points on an Expansion
Peripheral
25-16
The display will look similar to the following for the discrete output:
show discrete analogs 2/3
The display will look similar to the following for the analog input:
6. Save the configuration.
(Dub)>show discrete outputs 2/12
ID - 2/12
Description - Output 12
Value - closed
(Dub)>
(Dub)>show discrete analogs 2/3
ID - 2/3
Description -
State - disable
Low Band - 0
High Band - 0
Hysteresis - 2
Interval - 0
Max Loop Value - 30
Min Loop Value - 30
Max Sensor Reading - 40
Min Sensor Reading - 40
Units - mA
Mode - current
Value - 0 mA
(Dub)>
