Remote RMX-3200 Version 5.2x Configuration Guide
Using Configuration Wizards: Using the bistate-alarms Wizard
26-6
Using the bistate-alarms Wizard
To configure bi-state points:
1. From the main prompt, access the
bistate-alarms wizard:
config use-wizard bistate-alarms
The bistate alarm entry wizard screen displays:
2. Enter the desired unit number (
0 is the base unit).
The wizard states which point is currently selected and prompts you for:
Choosing a different point (range 1 - 64)
Configuring the selected point
Ending the configuration
3. (optional) Enter a description for the point when prompted.
4. Enter the desired alarm name when prompted.
5. Select the state of the point when it is alarmed (open/close) when prompted.
6. Select the desired severity level for the alarmed point from the list presented.
7. Enter a new alarm message or accept the default alarm message when
prompted.
In this scenario, you will configure a bi-state point on Remote RMX-3200 with the
bistate-alarms wizard. The wizard prompts you for all of the required and optional
configuration information
Note: This wizard also allows you to configure bi-state points on expansion units.
(Dub)>config use-wizard bistate-alarms
--------------------------------------
----- bistate alarm entry wizard -----
--------------------------------------
This wizard configures alarm entries for bistate (discrete input) points.
Ctrl-c aborts the wizard.
NOTE:
This wizard provides only basic configuration. For additional configuration
options, consult the command reference guide.
Enter number of the unit containing point(s) to configure. Use 0 or blank for
the base unit. Use 1-12 for a peripheral unit.
Enter unit number (leave blank for base unit):
