Kentrox RMX-3200 - Manually Configuring TBOS Display Points

Remote RMX-3200 Version 5.2x Configuration Guide
Configuring TBOS Settings: Manually Configuring TBOS Display Points
21-11
Manually Configuring TBOS Display Points

Note: Manually configuring TBOS points is not a common procedure. Generally,
TBOS points are configured using equipment types from a TBOS definition
file. For more information on this, refer to sections
TBOS Definition File
Support on page 21-3 and Configuring an Equipment Type for a TBOS
Display on page 21-8.
To manually configure the TBOS display point:
1. (optional) Configure TBOS port description
TBOS port 5 for TBOS port serial
5:
config tbos port serial 5 description TBOS port 5
2. (optional) Configure description Antennae Failure for TBOS point 6 in display 2:
config tbos port serial 5 display 2 point 6 description Antennae
Failure
3. Configure alarm severity level major and message Antennae Failure for TBOS
point
6 in display 2:
config tbos port serial 5 display 2 point 6 message major Antennae
Failure
4. Enable TBOS point 6 in display 2:
config tbos port serial 5 display 2 point 6 enable
5. Enable polling on display 2 and serial 5:
config tbos port serial 5 display 2 enable
config tbos port serial 5 enable
6. Enable SNMP traps in the Central Alarm Table:
config alarm-entry * trap enable
In this scenario, you will:
 Configure a TBOS port description.
 Configure a TBOS point description.
 Configure an alarm severity level and message for the TBOS point.
 Enable polling on the display.
 Enable SNMP traps in the central alarm table.
