Remote RMX-3200 Version 5.2x Configuration Guide
Configuring Relay Outputs: Overview
20-2
Overview
In this chapter, you will complete a scenario that activates a relay output using a TL1
command. You will configure a
Varbind (VNE) to generate an event when it receives a
specific
TL1 command. Relay outputs have two states: open and close.
You will configure a VNE to generate an event when a matching TL1 command is
received. The TL1 VNE will compare the incoming command code, TID and AID
against a configured command. If there is a match, the TL1 VNE will generate the
event, which triggers the response to turn on the device (a fan).
Note: For more information on how to configure a TL1 multiplexer and a TL1 VNE,
refer to
Configuring a TL1 Multiplexer on page 18-3 and Configuring a Virtual
TL1 NE on page 18-4.
