Kentrox RMX-3200 - Configuring STP on the Bridge Group

Remote RMX-3200 Version 5.2x Configuration Guide
Configuring the Bridge Group: Configuring STP on the Bridge Group
9-5
Configuring STP on the Bridge Group
To configure STP on the bridge group:
1. At the prompt, configure the STP forward delay time as
20 seconds:
config controller bridge switch stp forward-delay 20
2. Configure the STP hello time as 5 seconds:
config controller bridge switch stp hello-time 5
3. Configure the maximum age before STP information is discarded as 30 seconds:
config controller bridge switch stp max-age 30
4. Configure the STP priority level as 10000:
config controller bridge switch stp priority 10000
5. (optional) Verify that bridge controller switch has been configured properly:
show controllers bridge switch
The command response similar to the following displays:
6. Save the configuration.
In this scenario, you will configure STP settings for the bridge group.
(Dub)>show controllers bridge switch
bridge switch system-name=br_switch status=enabled oper-state=up stp=enabled
forward-delay=20 hello-time=5 max-age=30 priority=10000
stp_root_bridge
description=10/100 ethernet switch
ethernet 1 cost=100 priority=128 stp_state=forwarding
ethernet 2 cost=100 priority=128 stp_state=disabled
ethernet 3 cost=10000 priority=120 stp_state=disabled
ethernet 4 cost=100 priority=128 stp_state=disabled
ethernet 5 cost=100 priority=128 stp_state=disabled
ethernet 6 cost=100 priority=128 stp_state=disabled
serial wan/1 group cost=100 priority=128 stp_state=unmanaged
serial 5 cost=100 priority=128 stp_state=unmanaged
(Dub)>
