Configuring a Serial Controller on an Expansion Peripheral
Serial controllers configured on RME-S8 ports are set up the same way as serial
controllers configured on on-board Remote RMX-3200 serial ports—the same
commands are used.
To configure a serial controller on an RME-S8 port:
1. Configure and enable controller
serial 3/4:
config controller serial 3/4 enable
2. Assign controller serial 3/4 as a resource:
config controller serial 3/4 assign
3. Configure description FA unit 3: port 4 for controller serial 3/4:
config controller serial 3/4 description FA unit 3: port 4
4. Configure controller serial 3/4 to accept (but not receive) mediation
connections:
config controller serial 3/4 application destination
5. (optional) Verify that controller serial 3/4 is configured properly:
show controllers serial 3/4
The display will look similar to the following for controller serial 3/4:
6. Save the configuration.
In this scenario, you will configure a serial controller on an RME-S8 port.
(Dub)>show controllers serial 3/4
serial 3/4 status=enabled link-state=down encapsulation= baud=9600 databits=8
stopbits=1 parity=none resource-state=assigned
flow-control=none
linemode=rs232
dial-timer=1
init-string=
connect-mode=
rts-connect-mode=on
dtr-connect-mode=on
disconnect-mode=
rts-disconnect-mode=off
dtr-disconnect-mode=off
parity-errors=0
description=FA unit 3: port 4
application=destination
(Dub)>
