Kentrox RMX-3200 - RME-1000 Expansion Unit

Remote RMX-3200 Version 5.2x Configuration Guide
Remote RMX-3200 Product Overview: Expansion Units and Peripherals
1-7
RME-1000 Expansion Unit
The RME-1000 expansion unit is a chassis that can hold up to three Expand
peripherals including any of the following:
 RME-S8 peripheral provides eight asynchronous serial ports
 RME-B64 peripheral provides 80 I/O ports
 RME-E8 peripheral provides eight Ethernet ports
The chassis has no intelligence; it is configured and controlled from the Remote RMX-
3200 host.
For details on RME-1000 and the individual plug-in peripherals, see
Chapter 25:
Configuring the Peripheral Management Subsystem.

Note: The RME-B64 peripheral replaces the Expand-FDCI; however, Kentrox will
continue to support the FDCI peripheral at this time.
Figure 1-5 RME-1000 Chassis with RME-S8 and RME-B64 Peripherals
FA Peripheral
FB64 Peripheral
Available Slot
