Kentrox RMX-3200 - Configuring SNMP to Operate a Relay Output

Remote RMX-3200 Version 5.2x Configuration Guide
Configuring Relay Outputs: Configuring SNMP to Operate a Relay Output
20-6
Configuring SNMP to Operate a Relay Output
To configure SNMP to manage a relay output:
1. Configure SNMP event
snmpClose with manager set output4_close:
config event snmpClose content snmp manager-set output4_close
2. Configure SNMP event snmpOpen with manager set output4_open:
config event snmpOpen content snmp manager-set output4_open
3. Configure response switchClose to close output 0/4:
config response switchClose content output 0/4 close
4. Configure response switchOpen to open output 0/4:
config response switchOpen content output 0/4 open
5. Configure action snmpOutputClose to associate event snmpClose with response
switchClose:
config action snmpOutputClose event snmpClose response switchClose
6. Configure action snmpOutputOpen to associate event snmpOpen with response
switchOpen:
config action snmpOutputOpen event snmpOpen response switchOpen
In this scenario, you will:
 Configure SNMP events to generate manager sets
 Configure relay output close and open responses
 Configure actions to associate the events with the responses.
