Kentrox RMX-3200 - Configuring a Measurement Table Entry for State Transitions and Durations

Remote RMX-3200 Version 5.2x Configuration Guide
Configuring Measurements and the Measurement Table: Configuring a Measurement Table Entry for
State Transitions and Durations
16-10
Configuring a Measurement Table Entry for State
Transitions and Durations
To configure a measurement table entry that tracks the number of times the alarm
table entry ExtTemp1 transitions to the major state:
1. At the main prompt, configure measurement table entry
ExtTemp1_Transitions
with description Number of External temperature high alarms:
config meas-table entry ExtTemp1_Transitions description Number of
External temperature high alarms
2. Configure the originator for this measurement with the following settings:
 Measurement function @state-transitions
 Originator alarm-entry ExtTemp1
 Active state major
config meas-table entry ExtTemp1_Transitions originator @state-
transitions (alarm-entry ExtTemp1, major)

Note: The measurement function @state-duration can be used to measure
the number of seconds an alarm is in the specified active state.
3. (optional) Verify that the measurement table entry has been configured properly:
show meas-table entries ExtTemp1_Transitions
In this scenario, you will:
 Configure a measurement table entry with name and description
 Configure the originator to use the @state-transitions function to measure
the number of state transitions
