Remote RMX-3200 Version 5.2x Configuration Guide

Remote RMX-3200 TL1 Commands: Overview

28-2

Overview

This chapter discusses the following topics:

 The default Remote RMX-3200 TL1 command set

 Recognizing the failure messages associated with TL1 commands that aren’t

supported by Remote RMX-3200.

You should be familiar with Remote RMX-3200 actions and TL1 on Remote RMX-

3200 before reading this chapter. For more information on these topics, refer to

Chapter 12: Configuring Actions, Events and Responses and Chapter 18:

Configuring and Connecting TL1 Infrastructure.
